STM8S003F3P6TR 8-bit Microcontroller

STM8S003F3P6TR 8-bit Microcontroller

The STM8S003F3P6TR from STMicroelectronics is a value-line 8-bit microcontroller featuring a 16 MHz STM8 core with Harvard architecture and 3-stage pipeline. It offers 8 KB Flash program memory, 1 KB RAM, and 128 bytes of true data EEPROM with 100k write/erase cycles. With a rich set of peripherals including 10-bit ADC, UART, SPI, I²C, and multiple timers, this MCU is ideal for industrial control, consumer electronics, automotive, LED lighting, and IoT applications.

Key Features:

- 16 MHz STM8 core with Harvard architecture

- 8 KB Flash | 1 KB RAM | 128 bytes EEPROM

- 2.95V – 5.5V operating voltage

- 10-bit ADC with up to 5 channels

- UART, SPI, I²C communication interfaces

- Advanced control timer, general-purpose timers, watchdog timers

- Up to 16 GPIOs

- Clock Security System (CSS)

- SWIM for fast programming and debugging

- Low power modes (wait, active-halt, halt)

- TSSOP20 package

- -40°C to +85°C operating temperature

Applications: Industrial control, consumer electronics, automotive, LED lighting, IoT devices, power supply control.
