PT4115EE89E High Brightness LED Driver IC - Now in Stock
We are pleased to announce the availability of the PT4115EE89E from CRM ICBG. This continuous conduction mode inductive step-down converter is designed for efficiently driving single or multiple series-connected LEDs from a voltage source higher than the total LED chain voltage.
Product Overview
The PT4115EE89E operates from an input supply between 6V and 50V and provides an externally adjustable output current of up to 1.5A. It includes the power switch and a high-side output current sensing circuit, which uses an external resistor to set the nominal average output current. A dedicated DIM input accepts either a DC voltage or a wide range of pulsed dimming, making it a highly versatile solution for modern lighting designs.
Key Features
- Wide Input Voltage Range: 6V to 50V
- High Output Current: Up to 1.5A
- High Efficiency: Up to 97%
- Dimming Control: Single pin on/off and brightness control using DC voltage or PWM
- Switching Frequency: Up to 1MHz
- High Accuracy: Typical 3% output current accuracy
- Hysteretic Control: No need for compensation
- Comprehensive Protection: Inherent open-circuit LED protection, Rcs open protection, and thermal shutdown
- Package: SOT89-5
Applications
- Low voltage halogen replacement LEDs
- Automotive lighting
- Low voltage industrial lighting
- LED back-up lighting
- Illuminated signs
- SELV lighting
- LCD TV backlighting
Why Choose the PT4115EE89E?
With its simple low parts count, wide input voltage range, and high efficiency, the PT4115EE89E is the ideal choice for space-constrained and power-sensitive LED driving applications. Its robust protection features ensure long-term reliability in demanding environments.
Contact Us for Pricing and Availability
Regency Semiconductors Pvt Ltd
Phone: +91-8591695392
Email: sales1@regencysemiconductors.com
Website: www.regencysemiconductors.com
Note: Specifications are subject to change without prior notice. Please refer to the official datasheet for complete technical details.
